Hose pump features

文字:[大][中][小]

Hose pump features



The industrial hose pump is one of the supporting equipment for the main machine of foamed concrete production line (foaming concrete block equipment, non-steaming aeration block equipment, foamed concrete block equipment, non-steaming aeration brick equipment, non-steaming aeration concrete block equipment, non-steaming aeration light brick equipment).


The industrial hose pump absorbs the foreign advanced technology and develops a new, multifunctional, multi-purpose industrial pump. It completely got rid of the traditional pump impeller and shaft seal operation mode, for the viscosity, corrosion, fluid impurities large medium transport has a great advantage, and the traditional transport pump is completely different from the principle, wide range of applications.


Hose pump features:


1. It belongs to positive displacement pump, with or without mechanical seal, strong self-priming capacity, self-cleaning and other characteristics!


2, no pump valve, stuffing box, will not produce sealed pump leakage and gas resistance phenomenon!


3, simple structure, strong adaptability, liquid, gas, slurry and viscous suspended materials can be transported, especially the smooth hose cavity can pump impurities of liquid. A variety of fiber objects and the particle size of the hose diameter less than 1/4 of the solid slurry, and do not cause any blockage.


4, do not need to pump before the operation, dry operation, will not produce the fault of the main shaft seal, pump suction liquid only contact with the hose, so it can transport rubber can withstand the corrosive and abrasive medium, can replace the general stainless steel pump.


5, can be positive and negative rotation, no set import and export, less power consumption, high hydraulic and volume efficiency.


6. With good metering capacity, it can be used as a metering pump, and the flow can be changed by selecting the size of the pipe and adjusting the speed. The flow range is wide (0.25 -- 35m3/h), and the metering accuracy is high.


7. The tubes are made of various materials (vinyl, nylon, rubber, silicone rubber, etc.), which are suitable for conveying various corrosive, toxic, aseptic, radioactive and other media. The inner diameter of the tube is 0.5-75mm, the working pressure can reach up to 0.98mpa, and the working temperature is --62~+260°C.


8. One pump head can be installed with 1-20 pipes or one pump can be installed with multiple groups of pump heads to work and simultaneously transport one or more kinds of media. 1 pump multi-purpose, 1 pump can replace a number of pumps (suction. Discharge can work at the same time), small working volume. High efficiency.
